OA-Edge T
Product Details
The OA-Edge T series is based on OPTEX's Active Infrared Triangulation Technology. Due to the modular design, you can upgrade the safety level of the sensor by adding additional modules.
Primary and Secondary Modules
The sensor can be assembled using primary and secondary modules according to the required safety level and the width of the swing door. For a standard configuration of two sensors installed on a door with a width of 900 cm (29.5 feet) only one primary module is required, and a maximum of 3 secondary modules can be connected to this primary module.
Monitoring Capability
The OA-Edge T has built-in monitoring capability. It monitors all its critical functions and notifies compatible controls when an error occurs. Self-monitoring capability ensures a higher level of performance over the life of the sensor.
Multiple Lengths
Sensor comes in 4 different lengths, 13.5", 34.5", 40", and 44" versions. Sticks can also be cut to length by installer if needed.
Applications
Key Features
- Modular Design
- Primary and Secondary Modules
- Monitoring Capability
