*Product discontinued, for reference only. For replacement, please see the Redscan Pro Series.
The REDSCAN RLS-3060SH is an innovative laser scan detector that can detect a moving object's size, speed, and distance from the detector and process that information with a unique algorithm. This results in a high-reliability detection of people with minimal false alarms. The detector can also be mounted vertically or horizontally according to the application and site conditions. When vertical detection area is selected, the 3060SH creates a 200ft. detection area that functions like an invisible wall. With four outputs for remote video applications and 8 independently adjustable detection areas and REDWALL event codes, the RLS-3060SH is the ideal detector for controlling PTZ cameras and is integrated with leading VMS platforms. When horizontal detection area is selected, the RLS-3060SH creates a detection area with a radius of 165ft. and an arc of 190°. The detection area can be set manually or automatically. If the automatic setting is used, the detector will set the proper detection area; even for complicated area shapes. REDSCAN is a sophisticated next-generation outdoor detector that streamlines video monitoring and reduces installation costs.
| Version 8 Updated: |
|
| Features: | ||
|
**LAC-1 Required tools for Proper Installation**
| For Installation Training and Certification for this product, please emailcertifications@optexamerica.com with the following information: | ||
Optex will send invite to online training for each technician provided (training is free, no limit on number of people getting trained) |
Product Discontinued
Certification Required
Applications
- Buildings
- Perimeter
- Approach
- Roof / Ceiling
- House
- Garden
- Garage
- Driveway
Key Features
- Innovative Laser technology
- Analog or IP
- identifies the size, speed and distance of a moving object
- unique detection algorithm
- UDP Broadcast
- UDP Unicast
- UDP Broadcast & TCP
- UDP Unicast & TCP
- First & Last Name
- Job Title
- Company Name
- Telephone Number
- Project Name
The Redscan RLS-3060L and RLS-3060SH both require PoE+.
The Redscan series generate a Redwall Event Code. This is a simple ASCII character code which can be sent via TCP/IP (for example to a VMS). The Redscan Event Code communication can be set as follows:
In addition to the above, with the RLS-2020 there is also an HTTPS integration.
It can be downloaded from the following link: http://www.optex.co.jp/e/redwall/download/
The following video presents the key features and differences of RLS-3060 firmware v8 vs v7.
If you are interested in getting Installation training and certification for Redscan, please email certifications@optexamerica.com with the following information:
Optex will send invite to online training for each technician provided (training is free, no limit on number of people getting trained)
FAQs
The Redscan RLS-3060L and RLS-3060SH both require PoE+.
The Redscan series generate a Redwall Event Code. This is a simple ASCII character code which can be sent via TCP/IP (for example to a VMS). The Redscan Event Code communication can be set as follows:
- UDP Broadcast
- UDP Unicast
- UDP Broadcast & TCP
- UDP Unicast & TCP
In addition to the above, with the RLS-2020 there is also an HTTPS integration.
It can be downloaded from the following link: http://www.optex.co.jp/e/redwall/download/
The following video presents the key features and differences of RLS-3060 firmware v8 vs v7.
If you are interested in getting Installation training and certification for Redscan, please email certifications@optexamerica.com with the following information:
- First & Last Name
- Job Title
- Company Name
- Telephone Number
- Project Name
Optex will send invite to online training for each technician provided (training is free, no limit on number of people getting trained)
